Fiber optic blank out sign
1.0 Blank Out Signs (General)
1.1 Fiber optic blank out signs are designed to display a single or multiple messages, clearly and legibly, under any lighting conditions when energized. When not energized the sign shall be completely blanked out with no ghost images under any lighting conditions.
1.2 Most messages listed in Manual of Uniform Traffic Control Devices are available. Custom messages to fit various traffic control situations are also available upon request.
1.3 Blank out sign messages are formed by rows of fiber optic glass bundles. The bundles, when energized shall be highly visible anywhere within a 60-degree cone centered about the optic axis.
2.0 One-Sided
2.1 A one sided sign (one way) shall have a hinged, extruded aluminum service door on one side only, containing a fiber optic module with the message(s) on it as described in 1.2. This arrangement allows the sign to display the message(s) in one direction.
2.2 The door of a one sided sign, when opened shall allow full access to all of the serviceable components in the sign.
3.0 Mechanical Construction
3.1 The sign shall be constructed using a weatherproof, aluminum housing consisting of an 8” deep, .125” thick, extruded aluminum body, and a .063” aluminum back. All corners are continuous TIG (Tungsten Inert Gas) welded to provide a weatherproof seal around the entire housing.
3.2 The door shall be constructed of .125” thick extruded aluminum. Two corners are continuous TIG welded with the other two screwed together to make one side of the door removable for installation of the fiber optic module (see 4.0). The door is fastened to the housing on the left by a full length, .040” x 1 ¼” open stainless steel hinge. The door shall be held secure onto a 3/4” wide by 5/32” thick neoprene gasket by one or more (depending on size) quarter-turn link locks.
3.3 A three-sided visor made of .063” aluminum may be fitted to the door to act as a sunshade and improve the visibility of the message.
3.4 Extremely large signs may be made up of several sections of signs as described above. This method of construction allows for access to specific areas of the sign for maintenance to be performed without opening the entire sign face.
3.5 All surfaces of the sign shall be etched and primed in accordance to industry standards before receiving appropriate color coats of industrial enamel.
3.6 All fasteners and hardware shall be corrosion resistant stainless steel. No tools are required for routine maintenance such as a lamp change.
4.0 Fiber Optic Module
4.1 The fiber optic module shall consist of a flat black, aluminum face-plate, .080” thick with the following components attached directly to it. The face-plate shall be inserted into the rear track of the extruded aluminum door.
4.2 The glass, fiber optic bundles are glued into an end-tip at the termination end and the common assembly at the other end, and then ground smooth, and optically polished to ensure maximum light transmission through the bundle.
4.3 The end-tip of black nylon is inserted into a punched hole in the face-plate and mechanically held in place by four crush ribs along the outside diameter of the end-tip. The end-tip, when installed on the face-plate shall not protrude more than 5/16”.
4.4 The color filter provides the message color and is made of tempered, optically correct glass and is in conformance with I.T.E. specifications. It is mounted with four screws between the common assembly and lamp. Color filter can be changed in the field without removing the module from the housing.
4.5 Each message is illuminated by at least two light sources (depending on the message). The glass bundles are arranged so that in the event of a failure of one of the light sources the other shall continue to provide a legible message by lighting every other point in the message (bifurcation of each point between the two light sources is available). No color shall appear in the output points when not energized, regardless of ambient light conditions.
4.6 Protection for the assembly shall be provided by a 1/8” thick matt/clear polycarbonate lens with anti-glare characteristics. The lens shall be inserted into the front track in the door.
5.0 Electrical
5.1 Type ENL lamps shall be used to illuminate the messages. They shall be 42 watt, 10.8 volt with a rated life of 8,000 hours. Two lamps shall be used per message (see 4.5) to provide fail-safe operation in the event of lamp failure.
5.2 Step-down transformers shall be used to reduce the incoming 120 volts A.C. to 10.8 volts A.C. The transformers shall be rated at 48.5 volt-amps and have a class “A” insulation and weatherproofing. A separate transformer shall be used with each lamp to provide further burnout protection.
5.3 A barrier type terminal strip is provided for electrical connection of field wires.
5.4 The power consumption per message shall be less than 90 watts with both lamps illuminated. The sign shall be capable of continuous operation over a range of temperatures of –35 degrees to +165 degrees Fahrenheit.
